Low Pressure Flexible Polyurethane Foam Insulation Machine For Anti Fatigue Mat Floor Kitchen Mat

Short Description:


Introduction

Details

Specification

Applications

Video

Product Tags

Low-pressure polyurethane foam machines can be used to produce a number of applications in which lower volumes, higher viscosities, or differing levels of viscosity between the various chemicals used in a mixture are required. To that point, low-pressure polyurethane foam machines are also an ideal choice when m壯陽藥
ultiple streams of chemicals need to be treated differently prior to mixture.






  • Previous:
  • Next:

  • Detailed Foam Injection Machine Parts:

    Material Tank

    Double interlining heating material tank with insulation outer layer, heart rapidly, low energy consumption. Liner, upper and low head all use stainless 304 material, upper head is precision machinery sealing equipped to make sure the air tight agitation.
    Metering pump
    High precision GPA and JR series gear metering pump (pressure-tolerant 4MPa、JR speed 26~130r.p.m ;GPA speed 100~ 480r.p.m ), make sure the metering and ration accurate and stable.
    Electrical control system
    Composed of Power switch, air switch,A.C. Contactor and whole machine engine power, heat lamp control element line,digital display temperature controller, digital display manometer, digital display tachometer, PC programmable controller(pouring time and automatic cleaning) to keep machine in good condition.

    Product Features of High Pressure PU Machine:

    1. Adopting three layer storage tank, stainless steel liner, sandwich type heating, outer wrapped with insulation layer, temperature adjustable, safe and energy saving;
    2. Adding material sample test system, which can be switched freely without affecting normal production, saves time and material;
    3. Low speed high precision metering pump, accurate ratio, random error within ±0.5%;
    4. Material flow rate and presure adjusted by converter motor with variable frequency regulation, high accuracy, simple and rapid ration adjusting;
    5. High-performance mixed device, accurately synchronous materials output, even mixture. New leakproof structure, cold water cycle interface reserved to ensure no blockage during long downtime;
    6. Adopting PLC and touch screen man-machine interface to control the injection, automatic cleaning and air flush, stable performance, high operability, automatically distinguish, diagnose and alarm abnormal situation, display abnormal factors.

    No. Item Technical parameter
    1 Foam application Flexible Foam
    2 Raw material viscosity(22℃) POLY ~3000MPasISO ~1000MPas
    3 Injection pressure 10-20Mpa(adjustable)
    4 Output (mixing ratio 1:1) 54~216g/min
    5 Mixing ratio range 100:28~48(adjustable)
    6 Injection time 0.5~99.99S(correct to 0.01S)
    7 Material temperature controlling error ±2℃
    8 Repeat injection accuracy ±1%
    9 Mixing head Four oil house,double oil cylinder
    10 Hydraulic system Output: 10L/minSystem pressure 10~20MPa
    11 Tank volume 500L
    15 Temperature control system Heat: 2×9Kw
    16 Input power Three-phase five-wire 380V

    Whether you are standing at the desk, cooking in the kitchen, washing in the laundry, repairing the car in the garage, you can use the mat.

    The anti-fatigue comfort mat is constructed from 9/10 inch advanced comfort PU foam which combines the advantage of gel and memory foam for best cushioning experience. Compared to other mats that use cheap polyurethane foams, this standing desk mat is more ergonomic and effective reducing stress and pressure on feet, knees and the lower back over long standing periods.

    elite anti-fatigue kitchen comfort mat Medical_box_bottom_left 场景2



    Polyurethane PU Desk Kitchen Standing Anti-fatigue Mats DIY
